Detailed Product Description
| Grade Ability:: |
30% |
Product Name: |
Road Leveling Machine |
| Steering: |
Hydraulic Steering |
Type: |
Double Drum Roller, Single Drum Roller |
| Use For: |
High-grade Highways, Airport Runways |
Engine Type: |
Cummins Engine |
Cummins Diesel Engine Double Drum Vibratory Roller , Road Leveling Machine
Quick Detail:
1, road roller, pavement roller, road leveling machine
2, For high-grade highways, railways, airport runways, dams and other large projects fill compaction
3, 10000-16000kg operation mass
Description:
Main Features:
1.LTP2030/LTP1826/LTP1016 low gravitational center designed for safe and comfortable operation.
2.LTP2030/LTP1826 adopt CUMMINS 6BTA diesel engine, Powerful strength ,which is suitable to all environments.
3.Three forward speed and two backward changes, Reinforced plastic spraying box and multi-layer water filter ensure the stability of the system.
4.Power strength:LTP1016/LTP1016H which adopted 4BT Cummins engine is suitable to all environments.
Applications:
For high-grade highways, railways, airport runways, dams and other large projects fill compaction, has a good plateau (altitude 3500m) job performance; may be compacted sand, semi-viscous and sticky soil exciting force large, affecting depth of one meter or more. Hydrostatic mechanical roller gravity itself, so that permanent deformation is compacted layer and dense. Is divided into two types of steel wheel and tire type.
Specifications:
|
Standard configuration
|
|
Model
|
Engine
|
Tire
|
Gear box
|
Other
|
|
LTP1016
|
Cummins 4BT3.9
|
Adjustable inflation smooth tire, front 4 rear 5
|
Adopt synchronizer special
gear box of front 3 and rear 2
|
1.electrical sprinkler
2.air conditioner cab
3.mechanical driving
|
|
LTP1826
|
Cummins 6BTA5.9
|
Adjustable inflation smooth tire, front 5 rear 6
|
|
LTP2030
|
|
LTP1016H
|
Cummins 4BT3.9
|
adjustable inflation smooth tire, front 4 rear 5
|
1.hydrostatic driving, CVT
2.driving element adopt the products of SAUER or REXROT
3.eletrical sprinkler
4.air conditioner cab
|
|
LTP1826H
LTP2030H
|
Cummins 6BTA5.9
|
Adjustable inflation smooth tire, front 5 rear 6
|
1.hydrostatic driving, CVT
2.driving element adopt the products of SAUER or REXROT
3.Two-way operating
4.eletrical sprinkler
5.air conditioner cab
|
|
(Main Technical Parameters)
|
|
|
|
MODEL
|
|
LTP2030
|
LTP1826
|
LTP1016
|
|
Operating mass
|
kg
|
20000/30000
|
18000/26000
|
10000/16000
|
|
Max.travel speed
|
km/h
|
20.75
|
20.75
|
20
|
|
Type quantity
|
|
5+6
|
5+6
|
4+5
|
|
Min. turning radius
|
mm
|
8000
|
8000
|
7500
|
|
The presses width
|
mm
|
2790
|
2790
|
2286
|
|
Grade ability
|
%
|
30
|
30
|
30
|
|
Overall dimension
|
mm
|
4950×2850×3240
|
4950×2850×3240
|
4780×2280×3200
|
|
Wheelbase
|
mm
|
3800
|
3800
|
3700
|
|
Diesel power
|
kw
|
125
|
125
|
75
|
|
Diesel model
|
|
6BTA5.9-C170
|
6BTA5.9-C170
|
4BT3.9-C100
|
|
(Main Technical Parameters)
|
|
|
|
MODEL
|
|
LTP2030H
|
LTP1826H
|
LTP1016H
|
|
Operating mass
|
kg
|
20000/30000
|
18000/26000
|
10000/16000
|
|
Max.travel speed
|
km/h
|
13
|
13
|
13
|
|
Type quantity
|
|
5+6
|
5+6
|
4+5
|
|
Min. turning radius
|
mm
|
8000
|
8000
|
7500
|
|
The presses width
|
mm
|
2790
|
2790
|
2286
|
|
Grade ability
|
%
|
25
|
25
|
30
|
|
Overall dimension
|
mm
|
4950×2850×3240
|
4950×2850×3240
|
4780×2280×3200
|
|
Wheelbase
|
mm
|
3800
|
3800
|
3700
|
|
Diesel power
|
kw
|
125
|
125
|
75
|
|
Diesel model
|
|
6BTA5.9-C170
|
6BTA5.9-C170
|
4BT3.9-C100
|
Competitive Advantage:
- Have strong design team, experience engineers supply good service;
- The quality is reliable, the appearance looks modern and fashion;
- Reasonable price.
